4.
5.
Fig. 9.4Fig. 9.5
NOTE:
In order to replace the batteries, press the lock button to disengage the battery
lock and remove the old batteries.
Press the ON/OFF button.
(Fig. 9.4)
The screen will display ‘Welcome’.
(Fig. 9.5)
17
Setting Up
Adjust the length of the Telescopic tube (FEP tube) to
fit your particular reservoir.
If you require a longer tube, it is provided on request.
(Fig. 10.1)
Fix the Telescopic tube as shown. The tube’s ends
have different diameters – fix it from the wider end.
(Fig. 10.2)
Choose the correct adapter for the bottle.
The threaded platform base of MICROLIT E-BURETTE
has a 30 mm screw thread. Five adapters are supplied
to suit containers with a 28, 32, 38, 40, 45 mm and
30 mm (inbuilt adapter) screw neck.
(Fig. 10.3)
10.
1.
2.
3.
4.
Fig. 10.1Fig. 10.2Fig. 10.3
Fix the adapter on the reservoir bottle
by screwing it in clockwise direction.
(Fig. 10.4)
Fig. 10.4
18
