4
START WITH INSTALLING THE CONTROL PANEL AND SIREN
Position the control panel near a mains socket and
within easy reach of the entry/exit door.
Before drilling holes, ensure that they are not near
hidden mains wiring and pipework.
When planning the wiring, avoid awkward cable runs
to the control panel, siren box, PIRs and door
contacts.
1
Install the control panel out of reach of young
children.
Mark for two vertical holes 60mm apart.
Use a power drill with a no. 6 masonry drill bit, and
drill two holes 25mm deep. Insert the masonry plugs.
Mount the fixing bracket and secure with the fixing
screws.
4
5
6
2 3
60mm
