ATS-6501 Users Guide
60
Figure 11 ATS 6501 Rear Panel Connections
Note: The Fiber Optic Connection is not currently enabled and is available for expanding the
system’s capabilities in the future. This fiber optic connection was replaced with a PLGR/DAGR
interface connector on the SAASM version.
3.3 Software
3.3.1 Current Version
ATS-6501: Users can obtain the current software version via the command port using the status
unit:ver command.
ATS-6501>status unit:ver
tflex-5-2-2
[OK] 2016-08-05T21:06:30Z
CAUTION: Do NOT remove the software flash while the unit is on, it may cause an
unrecoverable error on the flash rendering the system inoperative.
GPS Receiver: Users can obtain the current GPS firmware version by sending the status
gps:model command.
ATS-6501>status gps:model
[hw_version] OEMV3G-4.01-X2T
[name] L12LV
[serial_number] DAB08410131
[sw_version] 3.701
[OK] 2013-08-05T21:07:04Z
WARNING: GPS Firmware [sw_version] 3.5 has a bug and should not be used. Contact
Microsemi if the ATS-6501 is operating with this version of the GPS Firmware.
3.3.2 Software Updates
Upgrading the software can be accomplished via two methods described below. Each release of
the software is accompanied by software release notes and, if needed, an updated manual.
