Hardware Components
UG0048 User Guide Revision 5.1 13
connected to a fixed 2.5 volts, which is required in ProASIC3 (LVDS only available in A3P250 and larger)
and ProASIC3E (LVDS available in all devices) for LVDS signaling.
For the location of J40 and J41 connectors on the ProASIC3/E Starter Kit board, see Figure 1, page 4.
Table 7 • FPGA – LVDS I/O Pin Details
FPGA Pin No. FPGA I/O Pin Name
1
1. Pin names are valid only for the A3PE600-PQ208 part. They are not correct for use with an A3P250.
2. J40: RJ45 connector is referred as CAT 5E PRIMARY connector.
3. J41: RJ45 connector is referred as CAT 5E SECONDARY connector.
Signal Name CAT5E Connector Pin No.
7 GAC2/IO132PDB7V1 TX1+ CAT 5E – PRI –1
8 IO132NDB7V1 TX1– CAT 5E – PRI –2
9 IO130PDB7V1 TX2+ CAT 5E – PRI – 5
10 IO130NDB7V1 TX2– CAT 5E – PRI – 4
11 IO127PDB7V1 RX1+ CAT 5E – PRI –3
12 IO127NDB7V1 RX1– CAT 5E – PRI – 6
13 IO126PDB7V0 RX2+ CAT 5E – PRI – 7
14 IO126NDB7V0 RX2– CAT 5E – PRI – 8
30 GFA2/IO117PDB6V1 TX3+ CAT 5E – SEC –3
31 IO117NDB6V1 TX3– CAT 5E – SEC –6
37 IO112PDB6V1 TX4+ CAT 5E – SEC – 7
38 IO112NDB6V1 TX4– CAT 5E – SEC – 8
42 IO106PDB6VO RX3+ CAT 5E – SEC –1
43 IO106NDB6V0 RX3– CAT 5E – SEC – 2
44 GEC1/IO104PDB6V0 RX4+ CAT 5E – SEC – 5
45 GEC0/IO104NDB6VO RX4– CAT 5E – SEC – 4
