Appendix: PQ208 Package Connections
UG0048 User Guide Revision 5.1 24
The following table lists the device connections for 208-Pin PQFP.
Table 9 • Device Connections for 208-Pin PQFP
208-Pin PQFP 208-Pin PQFP 208-Pin PQFP
Pin
Number A3PE1500 Function
Pin
Number A3PE1500 Function
Pin
Number A3PE1500 Function
1GND 36VCC 71 VCC
2 GNDQ 37 IO184PDB6V2 72 VCCIB5
3 VMV7 38 IO184NDB6V2 73 IO145NDB5V1
4 GAB2/IO220PSB7V3 39 IO180PSB6V1 74 IO145PDB5V1
5 GAA2/IO221PDB7V3 40 VCCIB6 75 IO143NDB5V1
6 IO221NDB7V3 41 GND 76 IO143PDB5V1
7 GAC2/IO219PDB7V3 42 IO176PDB6V1 77 IO137NDB5V0
8 IO219NDB7V3 43 IO176NDB6V1 78 IO137PDB5V0
9 IO215PDB7V3 44 GEC1/IO169PDB6V0 79 IO135NDB5V0
10 IO215NDB7V3 45 GEC0/IO169NDB6V0 80 IO135PDB5V0
11 IO212PDB7V2 46 GEB1/IO168PPB6V0 81 GND
12 IO212NDB7V2 47 GEA1/IO167PPB6V0 82 IO131NDB4V2
13 IO208PDB7V2 48 GEB0/IO168NPB6V0 83 IO131PDB4V2
14 IO208NDB7V2 49 GEA0/IO167NPB6V0 84 IO129NDB4V2
15 IO204PSB7V1 50 VMV6 85 IO129PDB4V2
16 VCC 51 GNDQ 86 IO127NDB4V2
17 GND 52 GND 87 IO127PDB4V2
18 VCCIB7 53 VMV5 88 VCC
19 IO200PDB7V1 54 GNDQ 89 VCCIB4
20 IO200NDB7V1 55 IO166NDB5V3 90 IO121NDB4V1
21 IO196PSB7V0 56 GEA2/IO166PDB5V3 91 IO121PDB4V1
22 GFC1/IO192PSB7V0 57 IO165NDB5V3 92 IO119NDB4V1
23 GFB1/IO191PDB7V0 58 GEB2/IO165PDB5V3 93 IO119PDB4V1
24 GFB0/IO191NDB7V0 59 IO164NDB5V3 94 IO113NDB4V0
25 VCOMPLF 60 GEC2/IO164PDB5V3 95 GDC2/IO113PDB4V0
26 GFA0/IO190NPB6V2 61 IO163PSB5V3 96 IO112NDB4V0
27 VCCPLF 62 VCCIB5 97 GND
28 GFA1/IO190PPB6V2 63 IO161PSB5V3 98 GDB2/IO112PDB4V0
29 GND 64 IO157NDB5V2 99 GDA2/IO111PSB4V0
30 GFA2/IO189PDB6V2 65 GND 100 GNDQ
31 IO189NDB6V2 66 IO157PDB5V2 101 TCK
32 GFB2/IO188PPB6V2 67 IO153NDB5V2 102 TDI
33 GFC2/IO187PPB6V2 68 IO153PDB5V2 103 TMS
34 IO188NPB6V2 69 IO149NDB5V1 104 VMV4
35 IO187NPB6V2 70 IO149PDB5V1 105 GND
