Appendix: PQ208 Package Connections
UG0048 User Guide Revision 5.1 25
Pin
Number A3PE1500 Function
Pin
Number A3PE1500 Function
Pin
Number A3PE1500 Function
106 VPUMP 141 GND 175 IO35PDB1V0
107 GNDQ 142 VCC 176 IO35NDB1V0
108 TDO 143 IO73NDB2V2 177 IO31PDB0V3
109 TRST 144 IO73PDB2V2 178 GND
110 VJTAG 145 IO71NDB2V2 179 IO31NDB0V3
111 VMV3 146 IO71PDB2V2 180 IO29PDB0V3
112 GDA0/IO110NPB3V2 147 IO67NDB2V1 181 IO29NDB0V3
113 GDB0/IO109NPB3V2 148 IO67PDB2V1 182 IO27PDB0V3
114 GDA1/IO110PPB3V2 149 IO65NDB2V1 183 IO27NDB0V3
115 GDB1/IO109PPB3V2 150 IO65PDB2V1 184 IO23PDB0V2
116 GDC0/IO108NDB3V2 151 GBC2/IO60PSB2V0 185 IO23NDB0V2
117 GDC1/IO108PDB3V2 152 GBA2/IO58PSB2V0 186 VCCIB0
118 IO105NDB3V2 153 GBB2/IO59PSB2V0 187 VCC
119 IO105PDB3V2 154 VMV2 188 IO18PDB0V2
120 IO101NDB3V1 155 GNDQ 189 IO18NDB0V2
121 IO101PDB3V1 156 GND 190 IO15PDB0V1
122 GND 157 VMV1 191 IO15NDB0V1
123 VCCIB3 158 GNDQ 192 IO12PSB0V1
124 GCC2/IO90PSB3V0 159 GBA1/IO57PDB1V3 193 IO11PDB0V1
125 GCB2/IO89PSB3V0 160 GBA0/IO57NDB1V3 194 IO11NDB0V1
126 NC 161 GBB1/IO56PDB1V3 195 GND
127 IO88NDB3V0 162 GND 196 IO08PDB0V1
128 GCA2/IO88PDB3V0 163 GBB0/IO56NDB1V3 197 IO08NDB0V1
129 GCA1/IO87PPB3V0 164 GBC1/IO55PDB1V3 198 IO05PDB0V0
130 GND 165 GBC0/IO55NDB1V3 199 IO05NDB0V0
131 VCCPLC 166 IO51PDB1V2 200 VCCIB0
132 GCA0/IO87NPB3V0 167 IO51NDB1V2 201 GAC1/IO02PDB0V0
133 VCOMPLC 168 IO47PDB1V1 202 GAC0/IO02NDB0V0
134 GCB0/IO86NDB2V3 169 IO47NDB1V1 203 GAB1/IO01PDB0V0
135 GCB1/IO86PDB2V3 170 VCCIB1 204 GAB0/IO01NDB0V0
136 GCC1/IO85PSB2V3 171 VCC 205 GAA1/IO00PDB0V0
137 IO83NDB2V3 172 IO43PSB1V1 206 GAA0/IO00NDB0V0
138 IO83PDB2V3 173 IO41PDB1V1 207 GNDQ
139 IO81PSB2V3 174 IO41NDB1V1 208 VMV0
140 VCCIB2
Table 9 • Device Connections for 208-Pin PQFP
208-Pin PQFP 208-Pin PQFP 208-Pin PQFP
