MSB780(X) - User’s Guide
14.7 V 1.3
Changes in this version are connected with hardware version 1.2.1 and firmware version 12 and
more.
• Changed picture in section Terminals.
• Changed typical power consumption @12 V from 67 mA to 32 mA. Power consumption
has lowered since new hw. ver. 1.2.1.
• Changed terminal markings TX, RX to TXD, RXD.
• Changed line termination from <cr><lf> to <cr>, or <cr><lf>. MSB780 accepts <cr> as an
alternative line ending since fw version 12.
• Changed default echo on to default echo off, with an option to turned echo on using a
command. This is valid since fw ver, 12.
• Renamed section "Notes on onboard jumper and trimmer" to "Note on onboard trimmer".
There is no more jumper on the PCB since fw. ver. 1.2.1.
• Changed example in section "Print configuration...". Since fw. ver. 12, the output of this
command looks differently.
• Added section "Get Verification (aV!)", which describes a new SDI-12 command, present
since fw. ver. 12.
14.8 V 1.4
Changes in this version are connected with hardware version 1.2.1 and firmware version 14 and
more. MSB780X version is first mentioned in this revision.
• Added hyperlinks to the document. References are now clickable in the electronic version.
• Added mention of MSB780X version at many places.
• Added table of supply currents.
• Added sections 2.9, 4.4, 6.4, 8.7, 8.7, 11
• Updated section Maintenance.
• Updated section Calibration and Adjustment
• Added new commands in the section Serial interface command set.
• Added table 10 representing error states.
• Renamed section 6.10, and updated.
• Added function HCP and related commands.
• Added section Display access.
99
