MSB780(X) - User’s Guide
model - model identification.
display - idicates the state of the display and its version.
probe - idicates the state of the external probe and its serial number.
serial - device serial number.
fw. ver - version of the firmware.
Sensor 1 - state of the sensor (OK or Error).
Sensor 1 s.n. - serial number of the sensor.
Sensor 2 - state of the sensor (OK or Error).
Sensor 2 s.n. - serial number of the sensor.
Sensor 3 - state of the sensor (OK or Error).
Sensor 3 s.n. - serial number of the sensor.
Coeff. ’k’ sensor 1 – correction gain for transducer 1.
Coeff. ’q’ sensor 1 - correction offset for transducer 1.
Coeff. ’k’ sensor 2 – correction gain for transducer 2.
Coeff. ’q’ sensor 2 - correction offset for transducer 2.
Coeff. ’k’ sensor 3 – correction gain for transducer 3.
Coeff. ’q’ sensor 3 - correction offset for transducer 3.
Coeff. ’k’ for 0..5V - correction gain for analog output range from 0 to 5 V.
Coeff. ’q’ for 0..5V - correction offset for analog output range from 0 to 5 V.
Coeff. ’k’ for 0..10V - correction gain for analog output range from 0 to 10 V.
Coeff. ’q’ for 0..10V - correction offset for analog output range from 0 to 10 V.
Coeff. ’k’ for 0..20mA - correction gain for analog output range from 0 to 20 mA.
Coeff. ’q’ for 0..20mA - correction offset for analog output range from 0 to 20 mA.
Analog out range - actual setting analog output mode (current or voltage) and range.
Analog out quantity - actual setting analog output quantity.
Quantity minimum - minimum value for quantity corresponding to minimum range output.
Quantity maximum - maximum value for quantity corresponding to maximum range output.
Analog out when error - value for analog output when quantity error.
Alarm quantity - actual setting of quantity watched by alarm.
Alarm minimum - minimum permitted value.
Alarm maximum - maximum permitted value.
sdi12 adr - the address of the sensor on SDI-12 bus.
barometer adr - the address of the barometer in POLL mode.
RS232 or RS485 speed – serial port Baud rate.
RS232 or RS485 dataBits – number of data bits.
RS232 or RS485 stopBits – number of stop bits.
RS232 or RS485 parity – parity parameter.
RS232 or RS485 echo - indicates RS232 echo state.
RS232 or RS485 SMODE - indicates of RS232 mode.
RS232 or RS485 INTV - number of time interval for RUN SMODE in second.
output format - actual FORM message format.
Actual UART - indicates of using interface.
Average time - setting the averaging time in seconds.
For MSB780X with more than 1 transducer, sensor states and coefficients k and q are displayed
for each transducer.
Analog output informations are valid only, if extension card is connected.
36
