MT-FP4060-UV Operating Manual
15
Main Board
Cleaning Board
Sensor Transfer Board
Main board cables
Power supply
Control panel
motor
Air extractor
Cleaning board
Sensor transfer board
Ink suction pump
Cleaning motor
Wiper sensor
Main board cable
Front position sensor
Left position sensor
Main board cable (signal)
Back position sensor
Power supply
