Servo motors
1.2.7 Main circuit boards
We use advanced motherboard, chip does not need ink and decoder, thereby reducing the volume of machines
Main board
Cleaning board
Sensor transfer
board
X-axis servo
Y-axis servo
Electric circuit control system
X-axis servo
motor
Y-axis servo
motor
Integrated servo
