Microtec UV6090 - 1.1 Machine structure overview and instruction

MT-FP4060-UV Operating Manual
4
Back-side appearance of printer
1.1.1 Machine Installation and Relevant Parameter
Machine Brand Name
MT-FP6090-UV (The short name: 6090-UV Direct Printer)
Interface
USB2.0
Power Requirement
50/60HZ 220V(±10%) ＜20A
Environment
20 ~ 28 ℃ HR40-60%
Print Head
Epson DX5 (Nozzles 180x8)
UV Curing System
LED UV Lamp (water cooling)
X/Y/Z-axis motors
Servo Motors
RIP Software
PhotoPrint RIP
Software Language
English/Chinese
Operation System
Microsoft Windows 98/2000/XP/Win7
Ink Type
UV Ink
Ink color
K C M Y W
Ink Supply System
CISS
Max. Print Format
60x90cm
Max. Print Gap
14cm
Machine N.W
146KG
Machine Dimension
140 x 130 x 55cm
Materials to Print
Metal, Plastics, Glass, Wood, Ceramics, Acrylic, Leather, etc
General Power Switch
USB Cable
Power Cable
Ground connection
sign and machine
serial number
