Microtec UV6090 - Page 28

MT-FP4060-UV Operating Manual
28
The fine-tuning data of Bi-direction readjustment is on the left, the offset adjustment data is on the right, pls. refer to
printed calibration chart as follows. Find out the most direct calibration data
Press button “Rightward” to enter
the interface of “BIDIRECTION
---TEST PRINT B”
Under “TEST PRINT B” press
button “ENTER” to make the test
printing
There’s 4 options here: 1,
2, 3, H
Press the "confirm" button
that can print in Bi-direction
