Chapter 2. Quick Start Guide of Oscilloscope
19
CH1、CH2、CH3、CH4 channel icons and vertical sensitivity icon. Tap the channel icons to open
channels; Click or to adjust the vertical sensitivity of channels; Open the channel menu by
swipe left from the desired channel and swipe right to close; Display the vertical sensitivity of
channels; Display couple method.
Trigger level adjustment, press on the button to modify the trigger level through upward and
downward movements.
Display areas of USB-PC connection, USB connection, battery level, time etc.
Trigger Mode: A(auto), N(Normal).
Automotive diagnostic software presets
Current channel selection. Click to pop up the current channel switching menu to switch the current
channel.
