6) Connect the probe to all other oscilloscope channels (Ch2 of a 2-channel oscilloscope, or Ch 2, 3 and 4 of a 4-
channel oscilloscope).
7) Repeat this step for each channel.
Warning
Ensure the wire insulation is in good condition to avoid probe electric shock while measuring high voltage.
Keep your fingers behind the probe safety ring to prevent electric shock.
When the probe is connected a voltage source, do not touch metal parts of the probe-head to prevent electric
shock.
Before any measurement, please correctly connect the probe ground end.
2.16 Modify the Language
To modify the display language, please refer to “14.3 Settings - Language and Input Method”.
