and ground. The output is square wave. Inductive type is generally 2-wire. The output is sensing signal; use BNC to
banana cable, one end is connected to channel 1 of the oscilloscope, and the other end is black The plug is
grounded, and the red connector is connected to the signal line of the distributor with a needle.
Use the SATO oscilloscope to test the distributor sensor (divided into two types: Hall effect and induction). The
specific operation is shown in Figure 3-17:
