Midas M32 Manual

47
M32 디지털 콘솔 사용자 매뉴얼
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate
0 dB to -1 dB 20 Hz – 20 kHz
Dynamic Range, Analogue In to Analogue Out
106 dB 22 Hz - 22 kHz unweighted
A/D Dynamic Range, Preamplifier and Converter (Typical)
109 dB 22 Hz - 22 kHz unweighted
D/A Dynamic Range, Converter and Output (Typical)
109 dB 22 Hz - 22 kHz unweighted
Crosstalk Rejection @ 1 kHz, Adjacent Channels
100 dB
Output level, XLR Connectors (Nominal / Maximum)
+4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced)
50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced)
20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors
+21 dBu
Output Level, TRS (Nominal / Maximum)
+4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced)
50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level
40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain
-85 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, Out 1-16 XLR Connectors, Muted
-88 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, TRS and Monitor out XLR Connectors
-83 dBu 22 Hz-22 kHz unweighted
Display
Main Screen
7”TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen
128 x 64 LCD with RGB Colour Backlight
Main Meter
24 Segment (-57 dB to Clip)
Power
Switch-Mode Power Supply
Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
Power Consumption
120 W
Physical
Standard Operating Temperature Range
5°C – 40°C (41°F – 104°F)
Dimensions
891 x 612 x 256 mm (35.1 x 23.9 x 10.1”)
Weight
24.5 kg (53.9 lbs)
SOUND SOLUTION

Midas M32 Specifications

General

Channels	40
Outputs	16 x XLR
Faders	25
Sample Rate	48 khz
Type	Digital
Talkback	1 x XLR
A/D Resolution	24-bit
Dynamic Processing	Yes
Control Surface	Yes
Effects	8 stereo effects processors
EQ	4-band
Display	7" TFT
Connectivity	Ethernet, USB
Inputs - Other	6 x Aux
Outputs - Main	2 x XLR
Outputs - Other	6 Aux, 2 FX
Data I/O	Ethernet, AES50
USB	1 x Type B
Computer Connectivity	USB, Ethernet
I/O Expansion Slots	1 x Expansion Slot
MIDI I/O	In/Out
Word Clock	In/Out
Depth	490 mm
Weight	15 kg
USB Audio Interface	32-in/32-out
Network Audio	AES50
Dimensions	760 x 168 x 490 mm
Inputs	32 x XLR/TRS combo
