Midas M32 Manual

46
M32 디지털 콘솔 사용자 매뉴얼
4. 부록
4.1 부록 A : Technical Specifications
Processing
Input Processing Channels
32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels
8 / 16
16 aux buses, 6 matrices, main LRC
100
Internal Effects Engines (True Stereo / Mono)
8 / 16
Internal Show Automation (structured Cues / Snippets)
500 / 100
Internal Total Recall Scenes (incl. Preamplifiers and Faders)
100
Signal Processing
40-Bit Floating Point
A/D Conversion (8-channel, 96 kHz ready)
24-Bit, 114 dB Dynamic Range A-weighted*
D/A Conversion (stereo, 96 kHz ready)
24-Bit, 120 dB Dynamic Range A-weighted*
I/O Latency (Console Input to Output)
0.8 ms
Network Latency (Stage Box In > Console > Stage Box Out)
1.1 ms
* A-weighted figures are typically ~3 dB
better
Connectors
MIDAS PRO Series Microphone Preamplifier (XLR)
32
Talkback Microphone Input (XLR)
1
RCA Inputs / Outputs
2/2
XLR Outputs
16
Monitoring Outputs (XLR / ¼”TRS Balanced)
2/2
Aux Inputs/Outputs (¼”TRS Balanced)
6/6
Phones Output (¼”TRS)
2 (Stereo)
Digital AES/EBU Output (XLR)
1
AES50 Ports (KLARK TEKNIK SuperMAC)
2
Expansion Card Interface
32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied)
1
MIDI Inputs / Outputs
1/1
USBType A (Audio and Data Import / Export)
1
USBType B, rear panel, for remote control
1
Ethernet, RJ45, rear panel, for remote control
1
Mic Input Characteristics
Design
MIDAS PRO Series
THD+N (0 dB gain, 0 dBu output)
< 0.01% unweighted
THD+N (+40 dB gain, 0 dBu to +20 dBu output)
< 0.03% unweighted
Input Impedance (Unbalanced / Balanced)
10 kΩ / 10 kΩ
Non-Clip Maximum Input Level
+23 dBu
Phantom Power (Switchable per Input)
+48 V
Equivalent Input Noise @ +45dB gain (150 Ω source)
-125 dBu 22 Hz-22 kHz unweighted
CMRR @ Unity Gain (Typical)
> 70 dB
CMRR @ 40 dB Gain (Typical)
> 90 dB
SOUND SOLUTION

Midas M32 Specifications

General

Channels	40
Outputs	16 x XLR
Faders	25
Sample Rate	48 khz
Type	Digital
Talkback	1 x XLR
A/D Resolution	24-bit
Dynamic Processing	Yes
Control Surface	Yes
Effects	8 stereo effects processors
EQ	4-band
Display	7" TFT
Connectivity	Ethernet, USB
Inputs - Other	6 x Aux
Outputs - Main	2 x XLR
Outputs - Other	6 Aux, 2 FX
Data I/O	Ethernet, AES50
USB	1 x Type B
Computer Connectivity	USB, Ethernet
I/O Expansion Slots	1 x Expansion Slot
MIDI I/O	In/Out
Word Clock	In/Out
Depth	490 mm
Weight	15 kg
USB Audio Interface	32-in/32-out
Network Audio	AES50
Dimensions	760 x 168 x 490 mm
Inputs	32 x XLR/TRS combo
