48 Chapter 6: Dual Stereo Input Channel
VeniceF
Operator Manual
EQ
Each dual stereo input channel of the VeniceF has a four-band, fixed EQ (treble and
bass shelving EQ and hi and lo mid EQ stages), allowing tonal control over the input
signal.
EQ section of the dual stereo input channels
Item Description
1 Treble control knob The treble shelving EQ gain is continuously variable
from -15dB to +15dB, with the shelf frequency set to 12kHz.
2 Hi mid control knob The hi mid gain is continuously variable from -15dB
to +15dB around 3kHz.
3 Lo mid control knob The lo mid gain is continuously variable from -15dB
to +15dB around 300Hz.
4 Bass control knob The bass shelving EQ gain is continuously variable
from -15dB to +15dB, with the shelf frequency set to 75Hz.
5 EQ switch and red LED The EQ switch enables the EQ. With EQ
disabled, adjustment of the EQ controls has no effect. This can be used to
compare the sound with and without EQ. The eq LED illuminates to show
that EQ is enabled.
