WIRE REMOTE CONTROLLER
1. Safety precaution
2. Installation accessory
Model
KJR-120M(X4)/BGEF, KJR-120M(X4W)/BGEF, KJR-120M(X5)/BGEF,
KJR-120M(X5W)/BGEF, KJR-120M(X6)/BGEF, KJR-120M(X6W)/BGEF,
KJR-120M1(X4)/BGEF
the wired remote controller you purchased (depend on model). The actual shape shall prevail.
Read this description carefully before installing or operating your wired remote controller.
•
Please entrust the distributor or professionals to install the unit.
•
Installation by other persons may lead to imperfect installation, electric shock or fre.
•
Adhere to this installation manual.
•
Imporper installation may lead to electric shock or fre.
•
Reinstallation must be performed by professionals.
Do not uninstall the unit randomly.
Random uninstalling may lead to abnormal operation, heating or fre of the air condition.
NOTE:
•
Do not install the unit in a place vulnerable to leakage of fammable gases.Once fammable gases are
leaked and left around the wire controller, fre may occure.
Select the installation location
Don’t install at the place where cover with heavy oil, vapor or sulfureted gas, otherwise, this product would
be deformed that would lead to system malfunction.
Preparation before installation
1. Please confrm that all the following parts you have been supply.
•
Do not operate with wet hands or let water enter the wire controller. Otherwise, electric shock may occur.
•
The wiring should adapt to the wire controller current.
Otherwise, electric leakage or heating may occur and result in fre.
•
The specifed cables shall be applied in the wiring. No external force may be applied to the terminal.
Otherwise, wire cut and heating may occur and result in fre.
1
2
3
4
5
3
2
M3.9*25 (For Mounting on the Wall)
M4X25 (For Mounting on switch box)
6
7
8
3
2
No. Name Qty. Remarks
Wire controller
Installation and owner’s manual
For Mounting on the Wall
Plastic screw bars
Screws
Wall plugs
For fixing on switch box
Optional
Screws
9
Screw
1
1
Battery
The connective wires group
1
1
1
M4X8(For Mounting the connective wire group)
To Next Page
