For exposed mounting, fasten the back plate on the wall with the 3 screws (ST3.9*25) and plugs. (Fig.3-3)
Use two M4X25 screws to install the back cover on the 86 switch box, and use one ST3.9*25 screw to fx to
the wall.
Screw hole fxed on the wall,useone ST3.9*25mm
Screw hole installed on 86 switch box, use two M4X25mm
3. Fasten the back plate of the wired controller
Fig 3-3
Back plate
Screws (ST3.9*25)
Fig 3-4
