14.Technical indication and requirement
15.Queries and settings
EMC and EMI comply with the CE certifcation requirements.
When the air conditioning unit is switch machine, Long press
“COPY” for 3 seconds , frst display P:00, if connected to an indoor unit, display
P:00, if connected to multiple indoor units, press “ ”or “ ”to display P:01, P:02,
and then press “Confrm” to enter the query indoor unit Tn(T1~T4) temperature and
fan fault(CF), press“ ”or “ ”to select.
Not operating keys 15 seconds or press “Back” or press “ON/OFF”drop out of
query temperature.
When the air conditioning unit is of, into the query function of temperature,
press“ ” or “ ”to select SP, press “Confrm” to adjust the static pressure value.
When the air conditioning unit is of, into the query function of temperature, press
“ ”or “ ”to select AF, press “Confrm” into test mode, press “Back” or press
“ON/OFF” or press “Confrm”drop out of test mode.In AF mode, 3~6 minutes test
completion automatically exits, if the test process, press “Back” or press “ON/OFF”
or press “Confrm” , the test exits will be interrupted.
When the air conditioning unit is of, into the query function of temperature, press
“ ”or “ ”to select tF.
The compensation temperature Range : -5~5°C.
Press “Confrm” into setting state, press“ ”or “ ”to select the temperature,
then press “Confrm” to complete it.
When the air conditioning unit is of, into the query function of temperature, press
“ ”or “ ”to select tyPE.
Press “Confrm” into setting state, press“ ”or “ ”to select the type, then press
“Confrm” to complete it.
When the air conditioning unit is of, into the query function of temperature, press
“ ”or “ ”to select tHI or tLo.
Press “Confrm” into setting state, press“ ”or “ ”to select the temperature, then
press “Confrm” to complete it.
The highest setting temperature range : 25~30°C
The lowest setting temperature range: 17 ~24°C.
: compensation temperature
Follow me function temperature compensation
Set the highest and lowest temperature values
CH:
CC: NA:
HH:
: Highest value setting function.
: Minimum value setting function.
