3 UNPACKING WAYS OF MAIN PARTS
1414
7. Undo the detergent box
I.Release the hose clamp
and pull out the inlet hose.
II.Release the hose clamp
and pull out the detergent
box hose, and then take
out the detergent box. 1.
IIII.Undo 2 screws between
cabinet and inlet valve.
Release the clamp fixing
the inlet valve and the
inlet hose, and then pull
out the inlet hose
8.Undo the pressure switch
I.Undo the top cover
II.Pull out the plugs on the
pressure switch.
II.Loosen the pressure
switch hose clamp, and
pull out the hose from the
pressure switch interface.
III.Rotate the pressure
switch anticlockwise by
90º, and then pull out the
pressure switch.
