4.Undo the door assembly
Undo the door
I.Open the door of
washing machine.
II.Take the outer gasket
III.Remove two screws on
the door and take down
the door .
Undo the door gasket
I.Remove the outer
gasket clamp between the
door seal and the front
plate. Loosen the inner
gasket clamp between
the door seal and the
front of the outer tub.
Undo the door lock
I.Remove two screws on
the door lock, and take
down the door lock.
II.Take out the door lock
and draw out the plug.
5. Undo the front plate
I.Remove the lower cover.
II.Undo 7 screws in
front plate
III.Put the front plate up to
the clasp of the front plate
away from the loading
holder, and then take off
the front plate.
6. Undo the facade
counterweight
I.Undo the front plate
II.Remove 4 screws pull
out the facade
counterweight.
3 UNPACKING WAYS OF MAIN PARTS
