Midea HS-338FWEN-W

20
Ambient temperature sensor
None
Ambient temperature sensor
Ambient temperature sensor is located in main control
board box and sends temperature signal to
microprocessor.
/
Freezer sensor
1） The sensor is located at the freezer chamberBefore
pull out the sensors,must be removed the air duct
cover of freezer chamber
2） Remove the sensors
8.6Compressor case
Rear cover and compressor case
None
Condenser fan moto
None
Terminal box of the compressor
None
Standby condenser
None
Piping system in the compressor case
1.Compressor
2.Exhaust transition pipe
5.Dry filter
6.Capillary
