Aqua Tempo Super II
201709 9
Part 2 - Component Layout and
Refrigerant Circuits
Figure 2-1.6: MC-SU60-RN1L top view
High pressure
sensor
High pressure
switch
Four-way valve
Electronic
expansion valve
Low pressure
switch
Solenoid
valve SV4
Discharge
temperature
switch
High pressure
gauge point
Low pressure
gauge point
