Midea Aqua Tempo Super II
Service Manual
2 Outdoor Unit PCBs
2.1 Types
Aqua Tempo Super II units have four PCBs – main control board, three phase AC filter board, DC fan inverter module board
and compressor inverter module board.
In addition to the four PCBs, MC-SU30-RN1L model each has one board while MC-SU30-RN1L model have one main control
board and the other boards each has two boards.
The locations of each PCB in the outdoor unit electric control boxes are shown in Figures 4-1.1 to 4-1.4 in Part 4, 1
“Outdoor Unit Electric Control Box Layout”.
2.2 Main PCB
Figure 4-2.1: Outdoor unit main PCB
1 2 3 4 5 6 7 8 9
36
35
34
33
32
31
30
10
11
12
13
14
15
16
29 28 27 26 25 24 23 22 21 20 19 18 17
Note:
1. Label descriptions are given in Table 4-2.1
