Midea MC-SU30-RN1L Service Manual

Aqua Tempo Super II
201709 99
Part
4 - Diagnosis and Troubleshooting
Table 5-5.4: Outdoor unit in heating mode operating parameters
Outdoor ambient temperature
°C
< -10
-10 to 0
0 to 7
7 to 20
> 20
Average discharge temperature
°C
40-95
42-96
44-97
45-97
50-98
Average discharge superheat
°C
17-35
17-35
17-35
17-33
14-33
Discharge pressure
MPa
1.7-2.6
1.8-2.8
1.9-3.3
2.2-3.5
2.3-3.8
Average suction superheat
°C
-2-0
-2-2
-1-4
0-6
1-8
Suction pressure
MPa
0.2-0.5
0.3-0.7
0.4-0.9
0.6-1.2
0.8-1.4
Average suction temperature
°C
-22 to -11
-16 to 2
-10 to 5
0 to 15
5 to 18
T3
°C
-20 to -11
-16 to 0
-10 to 2
1 to 12
5 to 15
Tz/7
°C
-19 to -4
-14 to 1
-5 to -2
1 to 6
2 to 10
Taf
°C
15-45
15-50
15-55
15-55
15-55
Twi
°C
15-40
15-45
15-50
15-50
15-50
Two
°C
18-45
18-50
18-55
18-55
18-55
Tw
°C
18-45
18-50
18-55
18-55
18-55
DC fan motor current
A
5-6
4-6
2-6
0.5-6
0.3-6
DC inverter compressor current
A
1-15
1-16
1-17
2-18
2-18
Note:
1. All the sensors please refer to Figure 2-2.1 and 2-2.2 in Part 2, 2 “Piping Diagrams”.
