4 - Diagnosis and Troubleshooting
Table 5-5.3: Inverter module temperature sensor resistance characteristics
Temperature
(°C )
Resistance
(kΩ)
Temperature
(°C )
Resistance
(kΩ)
Temperature
(°C )
Resistance
(kΩ)
Temperature
(°C )
Resistance
(kΩ)
-30
971.4
10
109.0
50
19.70
90
5.000
-29
912.8
11
103.9
51
18.97
91
4.855
-28
858.2
12
99.02
52
18.26
92
4.705
-27
807.3
13
94.44
53
17.59
93
4.566
-26
759.7
14
90.11
54
16.94
94
4.431
-25
715.3
15
86.00
55
16.32
95
4.301
-24
673.6
16
82.09
56
15.73
96
4.176
-23
634.7
17
78.38
57
15.16
97
4.055
-22
598.2
18
74.87
58
14.62
98
3.938
-21
564.1
19
71.53
59
14.10
99
3.825
-20
532.2
20
68.36
60
13.60
100
3.716
-19
502.2
21
65.34
61
13.12
101
3.613
-18
474.1
22
62.47
62
12.65
102
3.514
-17
447.7
23
59.75
63
12.22
103
3.418
-16
423.0
24
57.17
64
11.79
104
3.326
-15
399.8
25
54.71
65
11.39
105
3.235
-14
378.0
26
52.36
66
10.99
106
3.148
-13
357.5
27
50.13
67
10.62
107
3.063
-12
338.2
28
48.01
68
10.25
108
2.982
-11
320.1
29
45.99
69
9.909
109
2.902
-10
303.1
30
44.07
70
9.576
110
2.826
-9
287.1
31
42.23
71
9.253
111
2.747
-8
272.0
32
40.48
72
8.947
112
2.672
-7
257.8
33
38.81
73
8.646
113
2.599
-6
244.4
34
37.23
74
8.362
114
2.528
-5
231.9
35
35.71
75
8.089
115
2.460
-4
220.0
36
34.27
76
7.821
116
2.390
-3
208.7
37
32.89
77
7.569
117
2.322
-2
198.2
38
31.58
78
7.323
118
2.256
-1
188.2
39
30.33
79
7.088
119
2.193
0
178.8
40
29.13
80
6.858
120
2.132
1
169.9
41
27.98
81
6.640
121
2.073
2
161.5
42
26.89
82
6.432
122
2.017
3
153.6
43
25.85
83
6.230
123
1.962
4
146.1
44
24.85
84
6.033
124
1.910
5
139.1
45
23.90
85
5.847
125
1.859
6
132.3
46
22.98
86
5.667
7
126.0
47
22.10
87
5.492
8
120.0
48
21.26
88
5.322
9
114.3
49
20.47
89
5.159
