7. SPARE PARTS
ELECTRIC MODEL
No.
Part Name
Quantity
1.1
Door Handle
1
1.2
Door Cover
1
1.3
Door Cover Back
1
1.4
Door Gasket
1
1.5
Door Hinge Assembly
2
1.6
Fixed Seat
2
2.1
Front Panel
1
2.2
Cover Switch
1
2.3
Front Panel Cover (2)
1
2.4
Door Pin
1
2.5
Front Panel Cover (1)
1
3.1
Front Air Flue Assembly
1
3.2
Lint Filter Assembly
1
3.3
Sponge
1
3.4
Front Support Assembly
1
3.5
Nut
2
3.6
Flat Gasket
2
3.7
Wheel Assembly
2
3.8
Humidity Sensor Cover
2
3.9
Filter Lint Cover
1
4
Adjustable Foot Assembly (Front left)
1
5
Base Subassembly
1
6.1
Volute
1
6.2
Thermostate
1
6.3
Nut
1
6.4
Impeller Assembly
1
6.5
Volute Cover
1
6.6
Temperature Sensor
1
6.7
Clip Spring
2
6.8
Single phase asynchronous motor
1
6.9
Support For Tensioner Pulley Assembly
1
6.10
Spring
1
6.11
Screw
1
6.12
Safety Switch
1
6.13
Motor Support
1
7
Heater Support
1
8
Heater
1

Midea MDD160-V052/F01-US1305 Specifications

General

Brand	Midea
Model	MDD160-V052/F01-US1305
Voltage	220-240V
Frequency	50 Hz
Energy Efficiency	A++
Color	White
Control Type	Electronic
Number of Programs	16
Child Lock	Yes
Auto Clean	Yes
Warranty	2 years
Power Consumption	2.2 kW
Dimensions (H x W x D)	850 x 600 x 690 mm
Delay Start	Yes
