8.2 Opening the uint
Cover 1/2/3 give access to the compartment of water pipes and water side heat exchanger.
Cover 4 give access to the electrical parts.
Cover 5/6 give access to the hydraulic compartment.
Fig. 8-3 Doors of 65KW
Cover 1 Cover 2
Cover 1/2/3 give access to the compartment of water pipes and water side heat exchanger.
Cover 4 give access to the electrical parts.
Cover 5/6 give access to the hydraulic compartment.
Cover 3
Cover 6 Cover 5 Cover 4
Fig. 8-4 Doors of 110KW
Cover1 Cover 2 Cover 3
Cover 6 Cover 5 Cover 4
12
