Service manual
- 20 -
9. Capacity table
9.1 MSG-30CR N1-QB9P
SUMMER
Coolin
mod
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 7.88 7.40 6.86 6.31 5.90 5.47
15ºC W Sensitive capacity kW 5.75 5.52 5.18 4.79 4.50 4.21
Input kW. 2.74 2.89 3.01 3.25 3.61 3.73
24ºC D Total capacity kW 8.53 8.15 7.62 7.20 6.71 6.19
17ºC W Sensitive capacity kW 6.27 6.07 5.79 5.51 5.17 4.79
Input kW. 2.82 2.98 3.10 3.35 3.72 3.85
27ºC D Total capacity kW 9.09 8.68
8.20
7.75 7.22 6.66
19ºC W Sensitive capacity kW 6.91 6.69
6.40
6.08 5.69 5.26
Input kW. 2.91 3.07
3.20
3.46 3.84 3.97
32ºC D Total capacity kW 10.12 9.71 9.39 8.73 7.98 7.52
23ºC W Sensitive capacity kW 7.79 7.57 7.37 6.90 6.38 6.09
Input kW. 3.03 3.19 3.33 3.59 3.99 4.13
OUTDOOR TEMPERATURE DRY
9.2 MSG-30HRN1-QB9P
SUMMER
Coolin
mod
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 7.88 7.40 6.86 6.31 5.90 5.47
15ºC W Sensitive capacity kW 5.75 5.52 5.18 4.79 4.50 4.21
Input kW. 2.74 2.89 3.01 3.25 3.61 3.73
24ºC D Total capacity kW 8.53 8.15 7.62 7.20 6.71 6.19
17ºC W Sensitive capacity kW 6.27 6.07 5.79 5.51 5.17 4.79
Input kW. 2.82 2.98 3.10 3.35 3.72 3.85
27ºC D Total capacity kW 9.09 8.68
8.20
7.75 7.22 6.66
19ºC W Sensitive capacity kW 6.91 6.69
6.40
6.08 5.69 5.26
Input kW. 2.91 3.07
3.20
3.46 3.84 3.97
32ºC D Total capacity kW 10.12 9.71 9.39 8.73 7.98 7.52
23ºC W Sensitive capacity kW 7.79 7.57 7.37 6.90 6.38 6.09
Input kW. 3.03 3.19 3.33 3.59 3.99 4.13
OUTDOOR TEMPERATURE DRY
WINTER
-7ºC D
-8ºC W
Capacity kW
10.37 9.10 8.33 7.31 6.30 5.53
Input kW.
3.33 3.03 2.81 2.60 2.27 2.06
Capacity kW
10.18 8.93 8.13 7.06 5.98 5.18
Input kW.
3.41 3.07 2.86 2.67 2.33 2.09
Capacity kW
10.09
8.79
8.03 6.88 5.66 4.69
Input kW.
3.51
3.10
2.95 2.73 2.41 2.20
Capacity kW
10.00 8.69 7.91 6.78 5.56 4.61
Input kW.
3.63 3.13 2.99 2.83 2.55 2.29
OUTDOOR CONDITIONS
Indoor
Conditions
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
15ºC
18ºC
20ºC
22ºC
