Service manual
- 5 -
3. Dimension
3.1 Indoor unit
Dimension
Mode
WH L
28K 1250 325 230
36K 1250 325 230
3.2 Outdoor unit
Dimension
Mode
WHDL1L2L3
28K 895 860 330 560 360 735
36K 895 860 330 560 360 735
