Service manual
- 21 -
9.3 MSG-36CRN1-QB8P
SUMMER
Coolin
mod
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 9.87 9.27 8.59 7.90 7.38 6.85
15ºC W Sensitive capacity kW 7.21 6.92 6.48 6.00 5.64 5.28
Input kW. 3.52 3.72 3.87 4.18 4.65 4.80
24ºC D Total capacity kW 10.69 10.21 9.54 9.02 8.41 7.75
17ºC W Sensitive capacity kW 7.85 7.61 7.25 6.90 6.47 6.00
Input kW. 3.64 3.84 4.00 4.32 4.80 4.96
27ºC D Total capacity kW 11.38 10.88
10.27
9.71 9.05 8.34
19ºC W Sensitive capacity kW 8.65 8.37
8.01
7.62 7.13 6.59
Input kW. 3.75 3.96
4.12
4.45 4.94 5.11
32ºC D Total capacity kW 12.68 12.16 11.76 10.94 10.00 9.42
23ºC W Sensitive capacity kW 9.76 9.48 9.23 8.64 8.00 7.63
Input kW. 3.90 4.11 4.28 4.63 5.14 5.31
OUTDOOR TEMPERATURE DRY
9.4 MSG-36HRN1-QB8P
SUMMER
Coolin
mod
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 9.87 9.27 8.59 7.90 7.38 6.85
15ºC W Sensitive capacity kW 7.21 6.92 6.48 6.00 5.64 5.28
Input kW. 3.52 3.72 3.87 4.18 4.65 4.80
24ºC D Total capacity kW 10.69 10.21 9.54 9.02 8.41 7.75
17ºC W Sensitive capacity kW 7.85 7.61 7.25 6.90 6.47 6.00
Input kW. 3.64 3.84 4.00 4.32 4.80 4.96
27ºC D Total capacity kW 11.38 10.88
10.27
9.71 9.05 8.34
19ºC W Sensitive capacity kW 8.65 8.37
8.01
7.62 7.13 6.59
Input kW. 3.75 3.96
4.12
4.45 4.94 5.11
32ºC D Total capacity kW 12.68 12.16 11.76 10.94 10.00 9.42
23ºC W Sensitive capacity kW 9.76 9.48 9.23 8.64 8.00 7.63
Input kW. 3.90 4.11 4.28 4.63 5.14 5.31
OUTDOOR TEMPERATURE DRY
WINTER
-7ºC D
-8ºC W
Capacity kW
13.14 11.53 10.56 9.27 7.98 7.01
Input kW.
4.42 4.02 3.74 3.46 3.02 2.73
Capacity kW
12.90 11.32 10.30 8.94 7.58 6.56
Input kW.
4.53 4.08 3.80 3.55 3.10 2.78
Capacity kW
12.79
11.14
10.18 8.72 7.17 5.95
Input kW.
4.66
4.12
3.91 3.63 3.20 2.93
Capacity kW
12.67 11.02 10.03 8.59 7.05 5.84
Input kW.
4.83 4.16 3.97 3.77 3.40 3.04
15ºC
18ºC
20ºC
22ºC
OUTDOOR CONDITIONS
Indoor
Conditions
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
