Midea MSG-30HRN2

Service manual
- 24 -
9.3 MSG-30CRN2
SUMMER
Coolin
g
mod
e
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 7.60 7.14 6.61 6.08 5.69 5.28
15ºC W Sensitive capacity kW 5.55 5.33 4.99 4.62 4.34 4.06
Input kW. 2.76 2.91 3.04 3.28 3.64 3.76
24ºC D Total capacity kW 8.23 7.86 7.35 6.94 6.47 5.97
17ºC W Sensitive capacity kW 6.05 5.86 5.58 5.31 4.98 4.62
Input kW. 2.85 3.01 3.13 3.38 3.76 3.89
27ºC D Total capacity kW 8.76 8.38
7.91
7.47 6.97 6.42
19ºC W Sensitive capacity kW 6.66 6.45
6.17
5.87 5.49 5.07
Input kW. 2.94 3.10
3.23
3.49 3.88 4.01
32ºC D Total capacity kW 9.76 9.36 9.06 8.42 7.70 7.25
23ºC W Sensitive capacity kW 7.52 7.30 7.11 6.65 6.16 5.88
Input kW. 3.06 3.22 3.36 3.63 4.03 4.17
OUTDOOR TEMPERATURE DRY
9.4 MSG-30HRN2
SUMMER
Coolin
g
mod
e
Indoor
Conditions
25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
21ºC D Total capacity kW 7.60 7.14 6.61 6.08 5.69 5.28
15ºC W Sensitive capacity kW 5.55 5.33 4.99 4.62 4.34 4.06
Input kW. 2.76 2.91 3.04 3.28 3.64 3.76
24ºC D Total capacity kW 8.23 7.86 7.35 6.94 6.47 5.97
17ºC W Sensitive capacity kW 6.05 5.86 5.58 5.31 4.98 4.62
Input kW. 2.85 3.01 3.13 3.38 3.76 3.89
27ºC D Total capacity kW 8.76 8.38
7.91
7.47 6.97 6.42
19ºC W Sensitive capacity kW 6.66 6.45
6.17
5.87 5.49 5.07
Input kW. 2.94 3.10
3.23
3.49 3.88 4.01
32ºC D Total capacity kW 9.76 9.36 9.06 8.42 7.70 7.25
23ºC W Sensitive capacity kW 7.52 7.30 7.11 6.65 6.16 5.88
Input kW. 3.06 3.22 3.36 3.63 4.03 4.17
OUTDOOR TEMPERATURE DRY
WINTER
-7ºC D
-8ºC W
Capacity kW
11.07 9.71 8.89 7.81 6.72 5.90
Input kW.
3.53 3.21 2.99 2.76 2.41 2.18
Capacity kW
10.86 9.53 8.67 7.53 6.39 5.53
Input kW.
3.62 3.26 3.03 2.84 2.48 2.22
Capacity kW
10.77
9.38
8.57 7.34 6.04 5.01
Input kW.
3.72
3.29
3.13 2.90 2.55 2.34
Capacity kW
10.67 9.28 8.44 7.24 5.94 4.92
Input kW.
3.85 3.32 3.17 3.01 2.71 2.43
15ºC
18ºC
20ºC
22ºC
OUTDOOR CONDITIONS
Indoor
Conditions
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
