Midea MV6-R335WV2RN1 Service Manual

V6R VRF 50Hz
5
Part 1
-
General Information
1.1.2 Fresh air processing unit
Table 1-1.3: Fresh air processing unit capacity range
Capacity
12.5kW
14kW
20kW
25kW
28kW
Capacity index
125
140
200
250
280
Notes:
1. V6R series outdoor units are compatible with the 2nd generation DC Fresh air processing unit.
1.2 Heat recovery ventilator
Table 1-1.4: Heat recovery ventilator capacity range
Capacity
200m
3
/h
300m
3
/h
400m
3
/h
500m
3
/h
800m
3
/h
1000m
3
/h
1500m
3
/h
2000m
3
/h
Notes:
1. V6R series outdoor units are compatible with the DC type heat recovery ventilator.
1.3 High Temperature Hydro Module
Table 1-1.5: 1.3 High Temperature Hydro Module capacity range
Capacity
14kW
Capacity index
140
1.4 Outdoor Units
Table 1-1.6: Outdoor unit capacity range
Capacity
Model Name
Combination Type
8HP
MV6-R252WV2RN1
/
10HP
MV6-R280WV2RN1
/
12HP
MV6-R335WV2RN1
/
14HP
MV6-R400WV2RN1
/
16HP
MV6-R450WV2RN1
/
18HP
MV6-R500WV2RN1
/
20HP
MV6-R560WV2RN1
10HP+10HP
22HP
MV6-R615WV2RN1
10HP+12HP
24HP
MV6-R680WV2RN1
10HP+14HP
26HP
MV6-R735WV2RN1
12HP+14HP
28HP
MV6-R785WV2RN1
12HP+16HP
30HP
MV6-R835WV2RN1
12HP+18HP
32HP
MV6-R900WV2RN1
16HP+16HP
34HP
MV6-R950WV2RN1
16HP+18HP
36HP
MV6-R1000WV2RN1
18HP+18HP
38HP
MV6-R1070WV2RN1
12HP+12HP+14HP
40HP
MV6-R1120WV2RN1
12HP+12HP+16HP
42HP
MV6-R1185WV2RN1
12HP+14HP+16HP
44HP
MV6-R1235WV2RN1
12HP+16HP+16HP
46HP
MV6-R1300WV2RN1
14HP+16HP+16HP
48HP
MV6-R1350WV2RN1
16HP+16HP+16HP
50HP
MV6-R1400WV2RN1
16HP+16HP+18HP
52HP
MV6-R1450WV2RN1
16HP+18HP+18HP
54HP
MV6-R1500WV2RN1
18HP+18HP+18HP
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.
