V6R VRF 50Hz
59
14-18HP
Figure 5-1.3: 14-18HP top layer of electric control box
Figure 5-1.4: 14-18HP bottom layer of electric control box
Main PCB
Filter board
Inductor
Communication terminals block
Power supply terminals
Inverter module
Reactor
Fan module
Fan module
