Midea UR-PC160E-DQ

Service Manual, 2016-12
19 / 39
1） Take down screws and gaskets on the
evaporator.
2） Remove the welding on inlet and outlet
tubes.
Components on the evaporator
Defrost sensor
The defrost sensor is located on back of the
evaporator.
Not replace
Sensor
Sensor in freezing chamber
None
Sensor in refrigerating chamber
1） To remove the sensor cover, you may
squeeze it up and down;Take the sensor out
from card slot.
Sensor in Variable temperature chamber
None
Ambient temperature sensor
None
8.7Compressor case
Rear cover and compressor case
