Midea UR-PC160E-DQ

Service Manual, 2016-12
21 / 39
1 Main control board box
Condenser-1(in)DrierCapillary
TubeTransition pipe
2 CapacitorCompressor coverCompressordrain
trayCondenser-2(out)
3 Suction conection Pipe
Condenser fan motor
Fan motor
None
Standby condenser
None
 8.8Temperaturecontrol panel
1. Remove the two screws linking the
temperature control board mounting box to the
box
