6.5 Overview of inside structure
Picture 1.Inside structure
Valve body *5
The main gas tupe
Bottom cup*5
Flame ignitor
Rotating motor
Thermo switch 55℃
normal open
Heating element (upper)
Lamp
Terminal block
Rotating motor
Heating element
(Bottom)
Cooling motor
