Midland CT990 instruction guide | 23
Technical specifications
Frequency bands 144-146MHz & 430-440MHz (Rx / Tx)
Memory channels 257
Power supply Li-Ion battery pack 7.4V/2800 mAh
Operating temperature -25°C to + 55°C
Working mode monoband/dualband
Output power 10W VHF/ UHF
Modulation F3E(FM)
Max frequency deviation ≤ ±5KHz
Spurious emissions < -60dB
Frequency stability ±2.5 ppm
Rx sensitivity < 0.2uV
Audio output power ≥ 500mW
Dimensions 140 x 60 x 35mm
Weight 310g
Specifications are subject to change without notice.
WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the
transceiver from the mains; the desktop charger must be positioned close to the
unit and easily accessible.
