Midland G9 - Technical Specifications

Midland G9/G9E Plus instruction guide | 23
Technical specifications
Channels G9 PLUS 8+16 preprogrammed (PMR446) + 1~69
(LPD)
G9E PLUS 8+16 preprogrammed (PMR446)
Frequency range 446.00625 ÷ 446.09375MHz (PMR446)
433.075 ÷ 434.775MHz (LPD)
Channel spacing 12.5 KHz (PMR446); 25 KHz (LPD)
Power supply 6+/- 10% Vdc
Temperature from -20° to +55°C
Dimensions (w/o batteries) 58 (L)x 110 (H)x32 (D) mm
Weight (w/o batteries) 114gr
Duty cycle TX 5%, RX 5%, stand-by 90%
Category B
Transmitter
Output power 10 or 500 mW (Selectable)
Modulation FM
Spurious rejection within European legal terms
Receiver
Sensitivity @ 12dB Sinad 0,35μV
Adjacent channel rejection 70dB
Audio output power 300mW @ 10% THD
Intermediate frequencies 1st :21,4 MHz ; 2nd:450 KHz
Jack for ext.mike and recharge stereo 2,5 mm
Jack for ext. speaker mono 3.5 mm
Maximum transmission
time in an hour
6 minutes, equivalent to a duty cycle
of 10%
