Installation instructions
Loosen the screws f.
Under no circumstances should
sealant find its way between the
frame of the top part of the hob and
the worktop.
This could cause difficulties or even
damage should the hob ever need to
be taken out for servicing. The rub-
ber edge
b under the top part of the
hob provides a sufficient seal for the
worktop
d.
Set the ceramic hob c in the cut-out
and centre it.
(The Miele inscription must be
legible at the front).
Turn the clamps outwards e and
tighten the screws (5).
Check that the hob unit (2) fits tightly
on to the worktop.
59
