Miele HR 1421 - Dual Fuel Range Dimensions; Standard Configuration Dimensions (HR 19 xx)

Dual Fuel Range dimensions
56
Dual Fuel Range HR 19xx with Standard Burner Configuration
(M Pro Power Plus)
HR 1924, HR 1934, HR 1935, HR 1936, HR 1954, HR 1955, HR1956
If a BTU-reducing kit is necessary, an authorized installer is required to modify
the product to meet ANSI Z21.
1
 In case of combustible materials, a minimum distance of 6" must be observed on each
side in addition to dimension .
, ,  The shaded area represents the installation area for the connections:
E = Electrical connection, W = Water connection, G = Gas connection
Position Dimensions Description
 13" (330mm) Maximum depth of top cabinet
 18" (457mm) Minimum distance to bottom edge of top cabinet
 35 1/2"–37"
(901–940mm)
Distance from the floor to cooktop surface
 10" (254mm) Minimum distance to combustible surfaces.
