Miele HR 1421 - BTU-Reducing Kit Dimensions (HR 195 x)

Dual Fuel Range dimensions
65
Dual Fuel Range HR 195x with BTU-reducing kit
(M Pro Power - Zero Gap)
HR1954, HR1955, HR1956
For Miele Range Hoods:
If a BTU-reducing kit is necessary, an authorized installer is required to modify
the product to meet ANSI Z21. Jets are a standard accessory and are getting
changed during installation, see "Combination Range with BTU-reducing kit".
1
, ,  The shaded area represents the installation area for the connections:
E = Electrical connection, W = Water connection, G = Gas connection
Position Dimensions Description
 13" (330mm) Maximum depth of top cabinet
 18" (457mm) Minimum distance to bottom edge of top cabinet
 35 1/2"–37"
(901–940mm)
Distance from the floor to cooktop surface
 10" (254mm) Minimum distance to combustible surfaces.
