Dual Fuel Range dimensions
73
Front side view of HR 1934
1 5/16"
1 11/16"
1/4"
1 9/16"
8 1/8"
(x)
35 1/2" - 37"
(65.2mm)
17 13/16"
28 5/8"
(864,4mm)
13/16"
35 15/16"
1 9/16"
1 3/4"
27 1/4"
(-1/16" / -2mm)
(452.2mm)
2 9/16"
(20.85mm)
(40mm)
(692mm)
(45mm)
(913mm)
(727mm)
(7mm)
(34mm)
(40mm)
(207mm)
(43mm)
(901.7mm - 939.8mm)
34"
1/8"
(3mm)
(x) = Depending on the appliance height adjustment:
5" - 6 1/2" (127 mm - 165.1 mm)
