Installation
Granite and marble worktops
a Worktop
b Hob
c Gap
As the hob and worktop cut-out may
differ, the size of the gap c can vary.
^
Make the worktop cut-out according
to the dimensions given in the
building-in dimension diagrams.
Remember to maintain a minimum
safety distance (see "Safety
instructions for installation").
^
Feed the hob connection cable down
through the cut-out in the worktop.
^
Centre the hob b in the cut-out.
^
Connect the hob to the mains (see
"Electrical connection").
^
Connect the appliance to the gas
supply (see "Gas connection").
^ Secure the appliance at the back and
front using the fixings supplied. See
"Securing the appliance".
^ Check that the hob works.
^ Seal the remaining gap c with a
silicone sealant that is heat-resistant
to at least 160 °C.
For granite and marble worktops,
only use silicone sealant that is
specially formulated for granite and
marble, and observe the sealant
manufacturer's instructions.
KM 2257-1
46
