Secure the appliance as shown, using
the fixings supplied.
20 mm worktop
30 mm worktop
40 mm worktop
After installation
Check that all the burners are operating
correctly.
The flame must not go out on the lowest
setting, or when the control is turned
quickly from a high to a low setting.
On the highest setting, the flame must
have a distinctive and visible core.
Securing the appliance
49
