Loading the dishwasher
31
Adjusting the upper basket
In order to gain more space for taller
pieces of crockery in the lower or upper
basket, the upper basket can be
adjusted on three levels with 2cm
between each level.
The upper basket can also be set at an
angle with one side high and the other
side low so that water can run off freely
from recesses. However, ensure that
the basket can slide smoothly in and
out of the cabinet.
Pull out the upper basket.
To raise the upper basket:
Pull the basket up until it clicks into
place.
To lower the upper basket:
Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers
securely back down into position.
Depending on the setting of the upper
basket, plates with the following
dimensions can be accommodated.
Dishwasher with cutlery basket
Upper
basket
level
Plate Ø in cm
Upper
basket
Lower
basket
Top 20 31
Middle 22 29
Bottom 24 27
