Venting system with plastic
piping
Plastic piping can be fitted using an
adapter.
The following items are required:
–
an adapter.
–
a wall vent kit* or window vent kit*.
–
suitable plastic piping, available from
a ventilation installer. Where the pipe
diameter is more than 100 mm, an
adapter is necessary (e.g. 100 to
125 mm) to connect the pipe to the
dryer.
(* optional accessory)
^
Fit the adapter (1) and pipe (2), as
shown.
Secure the tumble dryer against
slippage, e.g. with clamps.
Example: Wall vent
1. Wall vent kit
(separate fitting instructions are
supplied with the Miele wall vent kit)
2. Adpater
3. Plastic piping,
diameter DN 100
Installation - extraction ducting
51
