Installation and connection
76
Rear view
a
Protruding lid for holding when mov‐
ing the dryer (see arrows)
b
Accessories for external drainage of
condensed water: hose clip, adapter
and hose holder
c
Hose for external drainage of con‐
densed wat
er
d
Mains connection cable
e
Communication module slot
Transporting the dryer
To manoeuvre the dryer out of its pack‐
ing
case to its installation site, hold it by
– the front feet
– and the lid where it protrudes at the
back of the appliance.
O
nly transport the dryer as
shown in the following illustrations.
I
f transporting the dryer at an an‐
gle, only tip towards the left side.
I
f the tumble dryer has not been
transported as described, then it
must be left to stand for at least 1
hour before it is connected to the
electricity supply.
Otherwise the heat pump can be
damaged.
